16 F6L-SS | Seal-Lok ORFS Straight Swivel F6L Tube Fitting

Parker 16 F6L-SS

Seal-Lok ORFS Straight Swivel F6L Tube Fitting

Parker's Seal-Lok O-Ring Face Seal fitting design provides leak-free connections in applications with high-pressure, vibration and impulse environments. The Seal-Lok fitting is an O-ring face seal type fitting that consists of a nut, a body, an O-ring and a sleeve. Using the new FastSeal nut, ORFS tube connections can be made in minutes without flanging or brazing.

Seal-Lok fittings have proven to be very effective in eliminating leakage at the higher pressures found in today€™s hydraulic systems. They are suitable for a wide range of tube wall thicknesses and are readily adaptable to pipe, inch or metric tubing and hose. Specifications:End 1:                                       1 inch

End 2:                                       1-11 1/2 NPTF

Material:                                    Stainless Steel

UOM:                                        EA

Trade Name:                            Seal-Lok

Series:                                      ORFS

Tube Fitting/Adapter Type:       ORFS, Seal-Lok O-Ring Face Seal

Configuration Type:                  Straight Swivel

Configuration Sub-Type:           Pipe Thread Swivel Connector

                                                  ORFS Swivel / NPTF

Inch/Metric                                Inch

End 1 Type:                              Inch

End 2 Type:                              NPTF
